| High-precision Cut-to-size Saw for Non-ferrous Metals Type-FTM |
|
 |
|
Feeder travel speed : |
|
|
|
forward |
up to 20 m/min |
66 ft/min |
|
back |
30 m/min |
98 ft/min |
|
Saw travel speed : |
|
|
|
forward |
0,1 - 60 m/min |
0,32 - 197 ft/min |
|
back |
60 m/min |
197 ft/min |
|
Clamp opening : |
|
|
|
|
180mm |
7.08“ |
|
Main saw motor power : |
|
|
|
|
44 kW |
55 HP |
|
Main saw blade : |
|
|
|
Diameter |
620 mm |
24.40“ |
|
Projection |
185 mm |
7.28“ |
|
Cutting height |
dep. on material/blade type |
|
|
Weight : |
|
|
|
FTM 430 |
ca. 14.000 kg |
31.000 lbs |
|
Cutting length : |
|
|
|
FTM 330 |
3300 mm |
129" |
|
FTM 430 |
4300 mm |
169" |
|
FTM 630 |
6300 mm |
248" | |
Benefits/Features FTM
Highest cut performance (AL 5083 thickness 120 mm, 3 m/min forward feed)
Highest accuracy (standard +- 0,1 mm, option +- 0,05 mm)
Highest productivity through Schelling turntable solution
Highest cleanness through Schelling chip conducting system (99,5% chiplessness)
|
